Descripción
Product Number MAP-T4PN-220PC-R1
CPU Socket LGA1200, LGA2066, LGA2011-v3, LGA2011, LGA1151, LGA1150, LGA1155, LGA1156, LGA1366, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1
Dimensions (L x W x H) 84 x 129 x 158.5 mm / 3.3 x 5.1 x 6.2 inch
Heat Sink Dimensions (L x W x H) 60 x 116 x 158.5 mm / 2.4 x 4.6 x 6.2 inch
Heat Sink Material 4 Heat Pipes, CDC 2.0, Aluminum Fins
Heat Sink Weight 420g / 0.93lb
Heat Pipe Dimensions Ø6mm
Fan Dimensions (L x W x H) 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch
Fan Speed 650-2000 RPM (PWM) ± 10%
Fan Airflow 66.7 CFM (Max)
Fan Air Pressure 2.34 mmH2O (Max)
Fan MTTF 160,000 Hours
Fan Power Connector 4-Pin (PWM)
Fan Rated Voltage 12 VDC
Fan Rated Current 0.28A
Fan Safety Current 0.37A
Fan Power Consumption 3.36W
Warranty 2 years
Serie MasterAir
Cooler Type Air Cooler
Heatpipes 4
